Gentex Pureflo Powered Respirator: PF23ESM

Skip to the beginning of the images gallery

Gentex Pureflo Powered Respirator: PF23ESM

Add to Wish List

£1,498.80 £1,249.00

Be the first to review this product

The ESM+ PF23 is an intrinsically safe self-contained, modular powered air purifying respirator designed for light duty industries including pharmaceutical, chemical, laboratory & healthcare. The ESM+ PF23 is approved for use in certain types of gas and dust environments where there are potentially explosive atmospheres.

The modular design enables it to be configured to exactly match the required application.
No trailing leads, hoses, or cables provides improved safety (no “snagging”) and permits use in wider range of applications compared to traditional back mounted powered respirators.
No belt mounted blower unit required thereby improving user comfort. Ideal for use with a range of protective workwear.

• Faceshield protection (certified to EN166 1.B.3.3)
• Lightweight fully integrated PAPR unit
• Configurable headpieces
• Highest protection levels
• Great field of view and optical quality
• Comfortable
• Easy to clean/decontaminate
• Low operating costs

Price includes 2 batteries (giving up to 8 hours use) 2 Chargers and Filter - ready to go

Filter for use with this unit is PR01020

SKU

PF23ESM-1

Categories: PPE Powered Respirators & Accessories Respirators

Guarantee safe & secure checkout

Details

Modular design: can be configured to exactly match the required application.
No requirement for face fit testing and can be used safely with beards and/or prescription spectacles.
Lightweight integrated respiratory, head, eye and face protection.
Proven low running costs with exceptional protection levels.
Includes 2 x 4-hour NiMH batteries and smart chargers, plus optional 16 station smart multi-charger.
Airflow rate of 220 l/m on P3 filter & 205 l/m on a ABE1P3 filter.
Sealed motor housing for ease of maintenance, enhanced cleaning and protection from contaminants.

INDUSTRIES
The PureFlo ESM + PF23 can be configured for use in multiple applications.
Pharmaceutical
Healthcare
Farming
Food Processing
Laboratories

Power Supply: Battery: 4 cell, nominal 4.8V, capacity 1.8 Ah per pack
Battery Life: 8 hrs (normal air-flow, two fully charged
battery packs fitted) Particulate Filter fitted PR01180
(Spare Part No. PR01020SP Qty 10) 6 hrs (normal air
flow, two fully charged battery packs fitted).
Odour/Particulate: Filter fitted PR01220 (Spare Part
No. PR01500SP Qty 10).
Charging Method/Rate: Mains charger, 2.5 hrs from
fully discharged.
Battery Charger: Mains Input: 110 240 volts a.c. /50 60 Hz / 200
mA Output, 10 volts d.c. /800 mA
Internal Fuse: 630 mA
Operational Temperature: +5°C to +40°C
Storage Temperature: 40°C to +70°C
Environmental: BS EN60529 Class IP30 (for indoor use
only) Double insulated
Choice of TH3P Filters: Nominal Protection Factor (NPF) 500
Faceshield: (certificated to EN166 1.B.3.9)
Non Incendive: Approved for use in Zone 2 hazardous environments
Conforms To: IEC 60079-15:2001 and IEC

Weight:1.5kg (nominal)

Filter for use with this unit is PR01020

Head Size Range: 54 - 61cm
Protection Factor: Laboratory 500
Assigned 40
Environmental Rating: IP54 Cat 2 ; IP44
Humidity: 0-90% (store out of direct sunlight)
Temperature Range: Charging: +5°C to +40°C
Use: -5°C to +40°C
Storage: +5°C to +40°C
Regulated Airflow: Normal 170 l/min

More Information

More Information
Manufacturer	Gentex
